Linux graphical problems with map

[Matsetes]

First, thanks to Paradox for supporting Linux gamers with all these ports to that magnificent OS!

I have a little problem with the map graphics: it is ok, but the resolution and the quality are very, very poor. It is ugly to see. I don't know what to do... I tried something found on the web, but nothing changed.

I have taken some screenshots:
http://i384.photobucket.com/albums/oo281/Matsetes/2015-08-15_00001.jpg
http://i384.photobucket.com/albums/oo281/Matsetes/2015-08-15_00002.jpg
http://i384.photobucket.com/albums/oo281/Matsetes/2015-08-15_00003.jpg

I am using Ubuntu on a laptop. I have Intel + Nvidia graphics card. I have tried also starting it with bumblebee or changing drivers on Nvidia graphic card.



[AndrewT]

Can you be more specific about what you see wrong in those screenshots?

Go to Steam-help-System Info. Paste everything there into here, except the Installed Software list at the end. thanks.



[Matsetes]

Perhaps the screens are not so clear, cause the resolution is less than the original 1080p. All the menus are graphically ok, but map, 3D people on the map and also the shields on it are quite pixelated and low graphics. It's like a 800x600 resolution map stretched to 1080p... And that is particularly clear when zooming. Also the map in the start menu is a lot low graphic and there are pixels of a strange green, like a phosphorescent one.
I wanted to deactivate something in the graphic options, but I saw that it is not like EUIV: you can only change resolution, Htz and Gamma...
I post here the informations you asked for. Perhaps it was better if posted on pastebin?

Spoiler

Informazioni sul processore:
Produttore: GenuineIntel
Famiglia della CPU: 0x6
Modello della CPU: 0x3a
Stepping della CPU: 0x9
Tipo di CPU: 0x0
Velocità: 1800 MHz
4 processori logici
2 processori fisici
HyperThreading: Supportato
FCMOV: Supportato
SSE2: Supportato
SSE3: Supportato
SSSE3: Supportato
SSE4a: Non supportato
SSE41: Supportato
SSE42: Supportato

Informazioni sulla rete:
Velocità della rete:

Versione del sistema operativo:
Ubuntu 14.04.3 LTS (64 bit)
Nome del kernel: Linux
Versione del kernel: 3.16.0-45-generic
Produttore dell'X Server: The X.Org Foundation
Versione dell'X Server: 11600000
Gestore dell'X Window: Compiz
Versione del Runtime di Steam: steam-runtime-release_2015-06-12

Scheda video:
Driver: Intel Open Source Technology Center Mesa DRI Intel(R) Ivybridge Mobile x86/MMX/SSE2
Versione dei driver: 3.0 Mesa 10.3.2
Versione dell'OpenGL: 3.0
Profondità di colore del desktop: 24 bit per pixel
Frequenza di aggiornamento del monitor: 60 Hz
VendorID: 0x8086
DeviceID: 0x166
Numero di monitor: 1
Numero di schede video logiche: 1
Risoluzione del display principale: 1920 x 1080
Risoluzione del desktop: 1920 x 1080
Dimensioni del display principale: 18,78" x 10,55" (21,54" diag)
47,7cm x 26,8cm (54,7cm diag)
VRAM principale non rilevata

Scheda audio:
Dispositivo audio: Intel PantherPoint HDMI

Memoria:
RAM: 7877 MB

Varie:
Lingua dell'interfaccia: Italiano
LINGUA: it_IT.UTF-8
Microfono: Not set
Spazio totale disponibile: 130404 MB
Blocco libero più ampio: 27255 MB

Rapporti sugli errori recenti:

Sorry for my very bad english



[AndrewT]

I still don't see the problem in those screenshots, sorry. Where are those stray pixels you mention?

Versione dei driver: 3.0 Mesa 10.3.2

The current driver is 10.6.4 - any reason why you are not using that?

You mention having an nVidia card too, but I don't see it in there. Are you sure the game is running on the nVidia?

Please attach your Documents/Paradox/CK2/settings.txt. From your Documents/Paradox/CK2/logs/ directory, post system.log (rename to system.txt to attach).



[Matsetes]

I solved, thanks to that topic (I'm sorry it's in Italian).
I think it was a problem with Nvidia drivers: I tried to change from the open source ones to the Nvidia binaries, but all I've got it's a black screen on start of pc. So CTRL+ALT+F2, login and

sudo apt-get install nvidia-current-updates

That returned me to the open source one, but after a

sudo apt-get update
sudo apt-get upgrade

I found new binaries for Nvidia GeForce GT 740M (my graphic card), so

sudo apt-get install nvidia-prime
sudo apt-get install nvidia-355
sudo apt-get install mesa utils

Reboot and now some errors but no black screen.
Then I opened Steam and it said the correct graphic card on the info (the ones posted before). I tried opening CK2 but it crashes in the same moment of opening the window. So I put in the launch options

optirun %command%

and of course

-skiplauncher

Now it works properly, with correct graphics...

I posted all that in case of someone having similar problems.

I have got another question: why without "optirun %command%" it crashes? Is it normal?

I tried searching in the packages the updated drivers for mesa, they are there, but trying to update them gives me tons of errors and the system cannot update them...



[AndrewT]

I have got another question: why without "optirun %command%" it crashes? Is it normal?

No, not at all.

I tried searching in the packages the updated drivers for mesa, they are there, but trying to update them gives me tons of errors and the system cannot update them...

I'm sorry, but I can't help you with that. Hopefully the nVidia Ubuntu community can!



[Matsetes]

Is it really necessary to update that drivers for mesa if I have solved with nVidia?
I don't know why it crashes without optirun, but I'm really happy to play that faboulous game on my Ubuntu partition =) Thanks Paradox



[AndrewT]

Is it really necessary to update that drivers for mesa if I have solved with nVidia?

Not for this purpose, no. It was just general advice.
